26/35kV 3 Core XLPE Insulated Power Cable for Industrial Energy
26/35kV 3 Core XLPE Insulated Power Cable for Industrial Energy
Our 26/35kV 3-Core Medium Voltage XLPE Insulated Power Cable is engineered for efficient and safe power distribution in industrial and utility networks.
Product Information
Model Number:
YJV (cross-linked polyethylene insulated, polyvinyl chloride sheathed power cable)
Insulation Material:
Xlpe
Type:
Medium Voltage
Conductor Material:
Copper
Jacket:
PVC (Polyvinyl Chloride)
Rated Voltage:
26/35KV
Product Details
Product Introduction
Our 26/35kV 3-Core Medium Voltage XLPE Insulated Power Cable is engineered for efficient and safe power distribution in industrial and utility networks. Designed and manufactured to international standards including IEC 60502, this cable features compact stranded copper conductors, triple-layer construction with conductor screen, cross-linked polyethylene (XLPE) insulation, insulation screen, copper tape shielding, and a durable PVC sheath. This robust XLPE Insulated Power Cable is ideal for supplying stable, high-quality power to critical industrial equipment, in both indoor and outdoor installations.
Features & Benefits
-
High-Temperature & High-Voltage Performance: The superior XLPE Insulated Power Cable core allows a maximum continuous conductor temperature of 90°C, with short-circuit tolerance up to 250°C. Rated at 26/35kV, it ensures reliable operation under demanding electrical loads.
-
Enhanced Safety & Durability: The semi-conductive screens ensure uniform electric field distribution, while the copper tape shield provides effective earth protection. The robust PVC sheath offers resistance to abrasion, moisture, and various environmental conditions, ensuring long-term operational safety.
-
Optimized for Industrial Use: This cable is designed to bear installation traction and is perfectly suited for supplying power to sensitive manufacturing facilities where voltage stability is paramount, such as cosmetic machinery plants in markets like the EU, Vietnam, and Southeast Asia.
-
Quality Assured Construction: From the Class 2 copper conductor to the flame-retardant sheath options (FR-PVC), every component is selected and tested to deliver consistent performance and longevity, making it a trustworthy XLPE Insulated Power Cable solution.
Why Choose Our Cable?
Shanghai Shenghua Cable is committed to being your reliable partner for critical power infrastructure. We understand that manufacturers, especially those in precision industries like cosmetics machinery, cannot afford downtime. Our cables are produced with stringent quality control, holding major certifications (CE, CCC, KEMA). We offer full technical support, from pre-sales consultation to after-sales service, with a 12-month warranty backed by PICC insurance. Our flexible packaging and on-time delivery commitment ensure your projects in North America, the EU, or Southeast Asia proceed smoothly without delay, supported by a 24/7 service hotline.
Technical Data Snapshot
|
Nom. Cross-Section
|
Insulation Thickness
|
Approx. Overall Diameter (O.D.)
|
Approx. Weight
|
Current Rating in Air (A)
|
|---|---|---|---|---|
|
3x95 mm²
|
10.5 mm
|
88.0 mm
|
8630 kg/km
|
280
|
|
3x150 mm²
|
10.5 mm
|
95.0 mm
|
11017 kg/km
|
360
|
|
3x240 mm²
|
10.5 mm
|
103.0 mm
|
14427 kg/km
|
470
|
(Partial table. Full range from 50mm² to 400mm² available.)
Rated Voltage: 26/35 kV | Test Voltage: 91 kV AC for 5 min | Min. Bending Radius: 15 x Cable O.D. (Multi-core)
FAQ
Q: What is the main advantage of choosing an XLPE Insulated Power Cable?
A: XLPE (Cross-linked Polyethylene) insulation provides excellent thermal stability, high dielectric strength, and superior aging resistance compared to traditional materials like PVC. This results in a more reliable, longer-lasting, and higher-capacity cable, essential for medium-voltage industrial power supply.
Q: Is this cable suitable for international projects in the EU or Southeast Asia?
A: Absolutely. Our XLPE Insulated Power Cable is designed to meet international IEC standards, which are widely recognized and accepted in the EU, North America, Vietnam, and across Southeast Asia. We also offer cables compliant with specific standards like BS or DIN upon request.
Q: What is your typical delivery time and warranty?
A: We prioritize on-time delivery to prevent project delays. Standard lead times apply, with detailed schedules provided upon quotation. Our products come with a comprehensive 12-month warranty from installation, supported by PICC insurance, and we guarantee a swift response to any service issues.
Q: Can you provide custom packaging?
A: Yes. We offer flexible packaging solutions including wooden reels, coils, or special packaging as per customer requirements to ensure the cable arrives at your site in perfect condition, ready for installation.
